SSRIF-1812
Specifications
| Bearing Type | |
| Product Category | |
| Sub Category | |
| Bore (d) |
0.5 in |
| Outside Diameter (D) |
1.125 in |
| Width (B) |
0.25 in |
| Ball Complement Number (Z) |
9 |
| Ball Complement Size (Db) |
0.15625 in |
| Dynamic Load Rating (C) |
684 |
| Flange Diameter (Df) |
1.225 in |
| Flange Width (Bf) |
0.062 in |
| Mini Shielded |
NO |
| Mini Flanged |
YES |
| Static Load Rating (Co) |
344 |
| Dynamic Load Rating (lbs) |
684 |
ABEC Grades 1, 3, 5, 7, and 9 may be available.
Request Information
Open flanged ribbon cage bearing
Flanged open ribbon cage bearing
