SSRIF-618SD504
Specifications
| Bearing Type | |
| Product Category | |
| Sub Category | |
| Bore (d) |
0.125 in |
| Outside Diameter (D) |
0.375 in |
| Width (B) |
0.1094 in |
| Ball Complement Number (Z) |
6 |
| Ball Complement Size (Db) |
0.0625 in |
| Dynamic Load Rating (C) |
60 |
| Flange Diameter (Df) |
0.412 in |
| Flange Width (Bf) |
0.023 in |
| Mini Shielded |
NO |
| Static Load Rating (Co) |
22 |
| Dynamic Load Rating (lbs) |
60 |
ABEC Grades 1, 3, 5, 7, and 9 may be available.
Request Information
Modified dimension flanged open crown cage bearing
Modified dimension open flanged crown cage bearing
